CUTLER HAMMER AN16GN0

0 $
Sin impuestos

Nema Starter, Size 2; 120VAC COIL

Cantidad
Entrega 10 días hábiles
equalizer Añadir a comparar cached
favorite_border Añadir a la lista de deseos cached

Nema Starter, Size 2; 120VAC COIL

Additional Features    :           Manual or Automatic Reset Function, Trip Indication
Brand/Series   :           AN16 Series
Coil Voltage    :           120 VAC
Cont Output Amp Rating       :           45 A
Current, Rating           :           45 A
Enclosure Type          :           Open
Horse Power Rating   :           25 HP
Horsepower, Max, 1 Phase, at 115 V           :           3
Horsepower, Max, 1 Phase, at 230 V           :           7.5
Horsepower, Max, 3 Phase, at 208 V           :           10
Horsepower, Max, 3 Phase, at 240 V           :           15
Horsepower, Max, 3 Phase, at 480 V           :           25
Horsepower, Max, 3 Phase, at 600 V           :           25
Motor Starter Functionality    :           Automatic, Manual
Motor Starter Type     :           DOL
Mounting Type           :           Screws Surface
NEMA Size     :           2
Number of Poles        :           3P
Overall Depth :           167.6 mm
Overall Dimensions    :           45 x 89.4 x 167.6 mm
Overall Length            :           45 mm
Overall Width  :           89.4 mm
Phase  :           3
Primary Type :           Starter
Relay Type     :           Overload
Series  :           Freedom
Special Features        :           Manual or Automatic Reset Function, Trip Indication
Standards       :           UL Listed, CSA Certified, VDE
Standards Met            :           CSA, NEMA, UL
Starter Type   :           Magnetic
Type    :           Non-Reversing
Voltage Rating            :           600 VAC
Voltage, Control         :           120/240 VAC
Voltage, Rating           :           110/120 (Coil) VAC

Ficha técnica



AN16GN0

Ficha de datos

Modelo
AN16GN0
Marca
CUTLER HAMMER
